Infrastructure
INFRASTRUCTURE
Infrastructure
| SHOP FACILITY | WORKING AREA | EOT capacity | PROCESS |
|---|---|---|---|
| Bay 1 | 20 M X 75 M | 20 T & 10 T | Assembly and welding- stainless steel / nickel & alloy fabrication |
| Bay 2 | 20 M X 75 M | 5 T | Assembly and welding for carbon steel fabrication |
| Bay 3 | 8 M X 40 M | 3 T | Raw material storage and cutting area |
| Bay 4 | 20 M X 40 M | 5 T | Assembly and welding for general purpose |
| Open yard | 25 M X 50 M | - | Storage |
| Office (Main) | 500 Sq.Mtr | - | Administration & design development |
| Covered Area | 4150 Sq.Mtr | - | Unit-1 & Unit-2 |
| Total Plant Area | 8500 Sq.Mtr | - | Unit-1 & Unit-2 |
LIST OF OUR MACHINERY
| SR NO. | DESCRIPTION | CAPACITY | QTY. |
| 1 | Loading / Unloading Facilities EOT CRANE | 3 TON 5 TON 10 TON 20 TON |
1 2 1 1 |
| 2 | VMC machine | 1000 MM DIA. X 800 MM x 150 MM THK. | 1 |
| 3 | Radial drilling machine | 80 MM X 2000 MM REACH. 40 MM X 1000 MM REACH |
2 2 |
| 4 | Plate rolling machine | 2.5 MTR. WIDTH X 25 MM THICK 2.0 MTR. WIDTH X 12 MM THICK |
1 1 |
| 5 | Ban saw machine | UP TO 350 MM DIA. | 1 |
| 6 | Lathe machine | UP TO 2000 MM DIA | 5 |
| 7 | Press Brake | 10 MM THK. X 3000 MM WIDTH | 1 |
| 8 | Plasma Power Source (Inverter based) with air cooled machine mounted and manual torches |
UP TO 100 MM THK (M.S) 40 MM THK. (S.S) | 1 |
| 9 | GTAW Power Source with water cooling system, TIG torch set and in-built HF |
400AMP | 5 |
| 10 | SMAW Machine, Rectifier based | 400AMP | 6 |
| 11 | Portable Grinders | 7 inch. and 5 inch | 20 |
| 12 | Hydro Test Pump (Motorized) | UP TO 210 KG | 1 |
| 13 | Hydro Test Pump (manual) | UP TO 100 KG | 4 |
| 14 | Welding Rotators | 20 TON 10 TON 5 TON |
1 2 2 |
| 15 | Gas Cutter Sets | AG 7 AG 5 |
1 1 |
| 16 | Mother Oven | 00 to 40000 (18" X 18")-(for Welding Electrodes) | 1 |
| 17 | Portable Oven | 00 to 1000 (for Welding Electrodes) | 5 |
| 18 | Pipe Cutting Machine | 1" TO 3" PIPE | 1 |
| 19 | Pug Cutting Machine | 2 | |
| 20 | Hand Cutting Set | 2 |
